美国Gearench摩擦钳、Gearench工具

Gearench公司位于德克萨斯州休斯敦市，它成立于1927年。其一款专利产品是一个用于小口径管子的手动工具。从这个工具开始，该公司已发展壮大成为超过40个产品线的企业，这些产品用于石油行业中的各个领域，包括勘探、钻井、成产、提炼和完成等工艺步骤。这些工具也在水井、非开挖技术钻井、采矿、发电应用和一般工业领域得到发展。

PETOL™管钳
PETOL™ Fitting Tongs
深圳市湾边贸易供应美国Gearench链钳
PETOL™管钳设计用于是弥补和突破具有狭窄或受限夹持区域的连接。钳子易于使用和拆卸，有两种尺寸，可以为工作提供适当的杠杆作用。
手柄采用落锻钢制成，并具有重型工字梁设计。两种尺寸均配有经过热处理的PETOL特殊链条，可以提供更长的长度，以加工更大的直径。

货号	管道尺寸	抓握宽度	钳子长度	重量	链条抗拉强度
C27-F	1/4" - 2-1/2"	.69"	23-1/4"	8 lbs.	13,800 lbs.
C57-F	1-1/2" - 8"	1.13"	54-1/2"	32 lbs.	22,000 lbs.

PETOL™超长链钳

货号	外径	重量
C27-34-F	1/2" - 7-1/4"	8-3/8 lbs.
C27-44-F	1/2" - 9"	9-1/2 lbs.
C27-56-F	1/2" - 11-3/4"	10-3/8 lbs.
C27-66-F	1/2" - 14"	11-1/8 lbs.
C27-78-F	1/2" - 17-1/2"	11-7/8 lbs.
C27-100-F	1/2" - 24"	13-3/4 lbs.
C57-54-F	1-7/8" - 15-1/2"	35-1/2 lbs.
C57-72-F	1-7/8" - 21-1/4"	39 lbs.

PETOL™-TITAN™链钳
PETOL™-TITAN™ Chain Tongs
PETOL™-TITAN™链条的出色品质确保了它们在现场提供更好的服务。钳口由优质钢锻造而成，并经过适当的淬火和回火处理，以承受苛刻的使用寿命。所有尺寸均配有热处理的PETOL™特殊链条。替换零件可与其他标准品牌的“单颚”链钳互换使。

货号	管道尺寸	抓握宽度	钳子长度	重量	链条抗拉强度
C11-P	1/8" - 1-1/2"	1.76"	20"	6 lbs.	9,400 lbs.
C12-P	1/4" - 2-1/2"	2.25"	27"	10 lbs.	13,800 lbs.
C13-P	3/4" - 4"	2.67"	37"	17 lbs.	17,600 lbs.
C135-P	1" - 6"	2.89"	45"	25 lbs.	20,100 lbs.
C14-P	1-1/2" - 8"	3.09"	51"	31 lbs.	22,000 lbs.
C15-P	2" - 12"	3.35"	65"	54 lbs.	31,000 lbs.
C16-P	4" - 18"	4.63"	87"	139 lbs.	56,000 lbs.

带有超长链条的PETOL™-TITAN™链钳

货号	外径	重量
C11-28-P	3/8" - 4-1/2"	6-1/4 lbs.
C11-36-P	3/8" - 6-1/4"	6-3/4 lbs.
C11-46-P	3/8" - 8-1/2"	7-1/4 lbs.
C11-54-P	3/8" - 10-3/4"	7-1/2 lbs.
C11-64-P	3/8" - 12-3/4"	8 lbs.
C11-72-P	3/8" - 15"	8-3/4 lbs.
C11-86-P	3/8" - 18-1/4"	9
C11-108-P	3/8" - 23-1/2"	10-1/8 lbs.
C12-34-P	1/2" - 7-1/4"	10-7/8 lbs.
C12-44-P	1/2" - 9"	11-1/2 lbs.
C12-56-P	1/2" - 11-3/4"	12-1/4 lbs.
C12-66-P	1/2" - 14"	13 lbs.
C12-78-P	1/2" - 17-1/2"	14-1/4 lbs.
C12-100-P	1/2" - 24"	15-1/2 lbs.
C13-36-P	1" - 8-1/4"	18-3/4 lbs.
C13-48-P	1" - 12"	20-1/4 lbs.
C13-60-P	1" - 15-3/4"	22 lbs.
C13-72-P	1" - 19-1/4"	23-1/2 lbs.
C13-84-P	1" - 23"	25-1/4 lbs.
C13-92-P	1" - 25-1/4"	29-1/4 lbs.
C135-46-P	1-3/8" - 12"	27-3/8 lbs.
C135-60-P	1-3/8" - 16-3/4"	29-5/8 lbs.
C135-76-P	1-3/8" - 22"	31-7/8 lbs.
C135-90-P	1-3/8" - 27"	34-1/8 lbs.
C135-106-P	1-3/8" - 32-1/2"	38-1/2 lbs.
C135-150-P	1-3/8" - 46-1/4"	45 lbs.
C14-54-P	1-7/8" - 15-1/2"	34 lbs.
C14-72-P	1-7/8" - 21-1/4"	36-3/4 lbs.
C15-52-P	2-3/8" - 18-3/4"	55-1/2 lbs.
C15-64-P	2-3/8" - 23-5/8"	59 lbs.
C15-84-P	2-3/8" - 31-3/4"	66-1/2 lbs.
C16-84-P	4-1/2" - 42-3/4"	174 lbs.

PETOL™-TITAN™可逆链钳
PETOL™-TITAN™ Reversible Chain Tongs
PETOL™-TITAN™可逆链条装箱允许操作员向任一方向转动管道，而无需移开钳子或解开链条。手柄采用落锻钢制成，并具有重型工字梁设计。钳口由特殊的优质钢锻造而成，并经过热处理以经受恶劣的工况。所有尺寸均配有热处理的PETOL™特殊链条。备用零件可与其他标准品牌的可逆链钳互换使用，并包装和贴有标签，以方便客户获取正确的原装PETOL-TITAN零件。

货号	管道尺寸	抓握宽度	钳子长度	重量	链条抗拉强度
C27-P	1/4" - 2-1/2"	2.19"	27"	11 lbs.	13,800 lbs.
C37-P	3/4" - 4"	2.69"	37"	19 lbs.	17,600 lbs.
C47-P	1" - 6"	3.00"	47"	27 lbs.	20,100 lbs.
C57-P	1-1/2" - 8"	3.38"	57"	40 lbs.	22,000 lbs.
C67-P	2" - 12"	3.69"	67"	59 lbs.	31,000 lbs.

带有超长链条的PETOL™-TITAN™可逆链钳

货号	外径	重量
C27-34-P	1/2" - 7-1/4"	11-1/4 lbs.
C27-44-P	1/2" - 9"	12-1/4 lbs.
C27-56-P	1/2" - 11-3/4"	13-1/4 lbs.
C27-66-P	1/2" - 14"	14-1/4 lbs.
C27-78-P	1/2" - 17-1/2"	15-3/8 lbs.
C27-100-P	1/2" - 24"	16-1/4 lbs.
C37-36-P	1" - 8-1/4"	19-3/4 lbs.
C37-48-P	1" - 12"	22-1/4 lbs.
C37-60-P	1" - 15-3/4"	23-1/4 lbs.
C37-72-P	1" - 19-1/4"	25 lbs.
C37-84-P	1" - 23"	26-3/4 lbs.
C47-46-P	1-3/8" - 12"	27-3/4 lbs.
C47-60-P	1-3/8" - 16-3/4"	31-1/2 lbs.
C47-76-P	1-3/8" - 22"	35-1/4 lbs.
C47-90-P	1-3/8" - 27"	38 lbs.
C47-106-P	1-3/8" - 32-1/2"	40-3/4 lbs.
C57-54-P	1-7/8" - 15-1/2"	42-3/4 lbs.
C57-72-P	1-7/8" - 21-1/4"	47-1/2 lbs.
C67-54-P	2-3/8" - 19-1/2"	60 lbs.
C67-84-P	2-3/8" - 31-3/4"	72 lbs.

货号	外径	抓握宽度	钳子长度	重量	链条抗拉强度
CPA13	1-1/2" - 6"	2.62"	30"	18 lbs.	17,600 lbs.
CPA14	2" - 10"	3.13"	44"	35 lbs.	22,000 lbs.
